FP862M

Pneumatic Hand Shears

TEXTILE
LEATHER
TECHNICAL
COMPOSITE
SPORT

Rasor’s new pneumatic FP862M is designed to cut a wide range of textiles, technical textiles, composites and other flexible materials up to a maximum thickness of 25mm. With a central placed “Monster” guiding foot, new turbine and steel gears, it is a powerful pneumatic cutter that effortlessly cut single and multi-layers of material, straight or contour. The turbine supply 400W @ 22.000 rpm.
High-quality HSS steel blades are available in a wide variety of shapes. A full carbide set-up makes the FP862M very suitable for your composite and anti-ballistic cutting applications.
This FP862M is designed with ease of use in mind. The finger protection and an auto-stop start lever make it a cutter that meets the highest safety requirements.
Experience the future of cutting technology with the new FP862M, a universal pneumatic cutting tool for a variety of industrial cutting applications.

For safety reasons we recommend wearing Rasor Safety Gloves when using our cutting machines.

GALLERY

VIDEO

SPECIFICATIONS

Blade diameter	86 mm (3.4″), with hard metal counterblade
Blade descr.	86THSS, 8-edges, HSS steel
Blade speed	1400 r.p.m*
Cutting ability	25 mm (1″)
Power	400W (at nominal air supply conditions)*
Working pressure	6 bar* (±1 bar) with lubricated air
Air consumption	9 l/sec*
Net weight	1100 g
Total weight (with packaging)	1995 g
Sound pressure	72 dB (EN ISO 15744)*
Vibrations at start up	1,36 m/sec2 (ISO 8662)*
Minimum brightness for working operations	LUX 200
Temperature range	0 – 55 C
Umidity range	10 – 95% without condensate * The reported data are collected at a pressure of 6 bar (ISO 2787: 1984), recommended operating pressure

Safety

Double safety start-up system device
Heigh-adjustable trasparent fore blade protection
Fixed trasparent back blade protection

FP862M
